- Place of Origin: china
- Brand Name: shengji
- Model Number: 60014
TECHNICAL STANDARD ON FABRIC REINFORCE CONCRETE PUMPING HOSE-80BAR:
Internal diameter | Outside diameter | Working pressures(bar) | Burst pressure(bar) | Bend radius | Weight(kgs/foot) | Ply |
1.25" | 1.841" | 80 | 220 | 8" | 0.46 | 4 |
1.5" | 2.209" | 80 | 220 | 9" | 0.55 | 4 |
2" | 2.953" | 80 | 220 | 11" | 0.85 | 6 |
2.5" | 3.535" | 80 | 220 | 12" | 1.13 | 6 |
3" | 4.213" | 80 | 220 | 13" | 1.49 | 8 |
3.5" | 4.803" | 80 | 220 | 17" | 1.77 | 8 |
4" | 5.315" | 80 | 220 | 21" | 2.25 | 8 |
4.5" | 5.748" | 80 | 220 | 23" | 2.55 | 10 |
5" | 6.496" | 80 | 220 | 25" | 3.11 | 10 |
Note:1.our hose is the best fabric hose made,the hose length is 10' to 50'. 2.available with metric or heavy duty ends and available with one or two ends. | ||||||
- Place of Origin: china
- Brand Name: shengji
- Model Number: 60014
